10″ Grizzly Bar Screener
Screen Angle: 42°
Bars: 4 tubing, 3/16 wall thickness
Weight: 3500 Ibs
Screener Specifications: 10′ Wide, 50″ Deep, 7′ High
Rock Break Down: 2″ minus -10″ minus. Factory set at 2″ minus adjustable in 1″ increments
Freight Dimensions: 7′ High, 5′ Long, 10′ Wide
Bolts: 1/2″ carriage bolts with 1″ spacing
Finish: Sherwin Williams primer and finish
14″ Grizzly Bar Screener
Description: Bar Slope 42°
Bars: 4″ tubing, 3/16 wall thickness
Weight: 5.500 lbs
Screen Specifications:, 14′ Long, 74″ Deep, 9’4″ High
Rock Break Down: 2″ minus -10″ minus. Factory set at 2″ minus adjustable in 1″ increments
Bolts: 1/2″ carriage bolts with 1″ spacing
Finish: Sherwin Williams primer and finish
Hauling: Hauling requirement is a step deck (legal transport)
