Showing all 14 results
2014 John Deere 326E Wheeled Skid Steer
$41,995.002949 Hours
****PRE EMMISSION ENGINE****
Cab
Heater
Air Conditioning
Radio
Horn
Self-Levelling
Reversing Fan
ISO Pilot Controls
Front Windshield Wiper And Washer
Two Speed With Creeper
Electic Quick Attach
Cloth Air Ride Seat
Foot And Hand Throttle
Front And Rear Lighting
Dual Beacon Lights
Auxiliary Hydraulics
14 Pin Electrical Connector
Just Changed Engine Oil And Filter (5W40 Full Synthetic) Inner And Outer Air Filter, Fuel Filter, Fuel Tank Breather Filter, Primary And Secondary Cab Filters, Hydraulic Filter, Checked Chain Case Oils, Checked Hydraulic Oil Level, Checked Windshield Washer Fluid.
Brand New Tires
Upgraded Front And Rear LED Lighting
New Tilt Cylinder To Quick Hitch Pins And Bushings
Quick Hitch Shimmed
C/w 96″ High Volume Snow Bucket
Municipal Unit Well Maintained
General Specifications
ENGINE POWER HP (KW)
|
74 (54.8)
Starting 2016 Model Year |
OPERATING LOAD LBS. (KG)
|
2,690 (1,221)
Starting 2016 Model Year |
OPERATING WIDTH IN. (CM)
|
72.6 (184)
Starting 2016 Model Year |
Axles
Maximum Axle Torque
|
5,680 lbs ft (7,701 nm)
|
Dimensions
Angle of departure
|
25 degrees
|
Ground Clearance
|
10 in (25 cm)
|
Height – Top of ROPS/FOPS
|
84 in (212 cm)
|
Hinge pin height, maximum height
|
125 in (318 cm)
|
Length w/o Bucket
|
10 ft (3 m)
|
Length with Bucket
|
13 ft (4 m)
|
Reach at Max Lift and Dump
|
40 in (102 cm)
|
Turning Radius – TTS870
|
7 ft (2 m)
|
Wheelbase
|
4 ft (1 m)
|
Engine
Air cleaner
|
Dry dual element
|
Bore
|
4 in (10 cm)
|
Displacement
|
201 cu in (3,300 cu cm)
|
Emissions Certification
|
Tier 4
|
Engine Make
|
Yanmar
|
Engine Model
|
4TNV98CT standard
|
Net Torque Rise
|
36%
|
Number of Cylinders
|
4
|
Power Measured @
|
2500 rpm
|
Stroke
|
4 in (11 cm)
|
Torque Measured @
|
1625 rpm
|
Hydraulic System
Hydraulic Horsepower-Standard Flow
|
42 hp (31 kw)
|
|
|
|
|
|
Loader
Boom breakout force
|
5,000 lbs (2,268 kg)
|
bucket breakout force (ISO 14397)
|
7,750 lbs (3,515 kg)
|
Dump angle @ max. height
|
45 degrees
|
Operating Load Rating
|
2,850 lbs (1,293 kg)
|
Operating Width
|
73 in (185 cm)
|
Rollback – Ground Level
|
35 degrees
|
Tipping load (ISO 14397)
|
5,400 lbs (2,449 kg)
|
Width without Bucket
|
6 ft (2 m)
|
Operating Specifications
Alternator Supplied Amperage
|
70 amps
|
Fuel Capacity
|
24 gal (92 l)
|
Hydraulic System Fluid Capacity
|
21 gal (80 l)
|
Max Speed
|
11 mph (18 kph)
|
Operating Voltage
|
12 volts
|
Operational Weight
|
8,200 lbs (3,719 kg)
|
$965.38/month OAC
